| Technical specification | ||||||
|---|---|---|---|---|---|---|
| Model | SN-1204 | SN-1304 | SN-1404 | SN-1504 | ||
| Drive Type | 4×4 4WD | |||||
| Engine | ||||||
| Engine Model | LR6B5-22 | LR6M5-22 | LR6M5-22 | LR6M5-22 | ||
| Capacity of fuel tank(L) | 240 | |||||
| Rated speed (r/min) | 2200 | |||||
| Engine power (kw) | 88.20 | 95.60 | 102.90 | 110.30 | ||
| Lowest fuel consumption (g/kw·h) | ≤242 | |||||
| Transmission | ||||||
| Clutch | Dry,dual-stage type | |||||
| PTO Speed(mm) | 540/1000 or 760/1000（optional） | |||||
| Gearshift | 16F+8R | |||||
| Three point linkage | ||||||
| Category of 3-point link | Rear,CategoryII | |||||
| Lifting capacity(at point of 610mm)KN | ＞22 | |||||
| Technical parameter | ||||||
| Dimension LxWxH mm | 5060x2345x2995 | |||||
| Wheel base(mm) | 2657 | |||||
| Track base(mm) front wheel | 1650-1950 | |||||
| Track base(mm) rear wheel | 1620-2420 | |||||
| The smallest clearance(mm) | 395 | |||||
| Front tyre | 12.4-24 | 14.9-26 | ||||
| Rear tyre | 16.9-34/18.4-30(optional) | 18.4-38 | ||||
