| Technical specification | ||||||||
|---|---|---|---|---|---|---|---|---|
| Tractor Model | SN-1604 | SN-1804 | SN-2004 | SN-2204 | SN-2804 | SN-4404 | ||
| Power | 160hp | 180hp | 200hp | 220hp | 280hp | 440hp | ||
| Type | 4x4 4 wheel drive | |||||||
| Dimension(mm) | 5840x3510x3280 | 5840x3710x3300 | 6020x3710x3300 | 6150x3800x3480 | 6150x3800x3490 | 7800x5100x4100 | ||
| Wheel base(mm) | 3080 | 3080 | 3080 | 3140 | 3140 | 3911 | ||
| Front Wheel Track(mm) | 1928-2240 | 1928-2240 | 1928-2240 | 2070-2154 | 2070-2154 | 2546 | ||
| Rear Wheel Track(mm) | 1952-2568 | 1952-2568 | 1952-2568 | 1966-2582 | 1966-2582 | 2546 | ||
| Min Ground Clearance(mm) | 450 | |||||||
| Min Running Weight(mm) | 7840 | 8000 | 8500 | 9600 | 10000 | 17830 | ||
| Front Ballast Weight(kg) | 500 | 500 | 500 | 1000 | 1300 | 1300 | ||
| Traction Force(KN) | 36 | 40 | 43 | 48 | 60 | 94 | ||
| Gear Shift | 14F+7R | 14F+7R | 24F+8R | 18F+9R | 18F+9R | 24F+12R | ||
| Diesel Engine | water cooled,six cylinders,2200rpm | |||||||
| Fuel consumption(g/kw.h) | <230 | |||||||
| Front Tyre Size | 14.9-28 | 16.9-28 | 16.9-28 | 18.4-30 | 18.4-30 | 20.8-42 | ||
| Rear Tyre Size | 18.4-38 | 20.8-38 | 20.8-38 | 20.8-38 | 20.8-38 | 20.8-42 | ||
| PTO Type | Rear position and independent | |||||||
| PTO Speed | 540/1000rpm | |||||||
| Forward Running speed(km/h) | 2-36 | |||||||
| Back Running speed(km/h) | 2-19 | |||||||
| Max.Lifting Force(kN) | 36 | 36 | 36 | 50 | 50 | 75 | ||
